PVD Silver Magnetron Sputtering Deposition System

Name: PVD Silver Magnetron Sputtering Deposition System
Brand: ROYAL
Price: 1 USD

China PVD Silver Magnetron Sputtering Deposition System wholesale

Brand Name : ROYAL

Model Number : RTSP1200

Certification : CE

Place of Origin : Made in China

MOQ : 1 set

Price : negotiable

Payment Terms : L/C, T/T

Supply Ability : 10 sets per month

Delivery Time : 8 to 12 weeks

Packaging Details : Export standard, to be packed in new cases/cartons, suitable for long-distance ocean/air and inland transportation.

Chamber : Vertical Orientation, 1-DOOR

Material : Stainless Steel 304/316

Film Features : High Reflective, Excellent Corrosion And Wear Resistance

name : copper Magnetron Sputtering System

technology : Vacuum Flask PVD Cooper Deposition

available : Multi layers coating

Factory Location : Shanghai city, China

Worldwide Service : Poland - Europe; Iran- West Asia & Middle East, Turkey, India, Mexico- South America

Training Service : Machine operation, maintenance, coating process Recipes, program

Warranty : Limited warranty 1 year for free, whole life for machine

OEM & ODM : available, we support tailor made design and fabrication

Contact Now

Magnetron Sputtering Deposition System , Sputtering Vacuum Coating Machine Silver Sputtering Deposition

Thanks for the Magnetron Sputtering Technology which represents a real alternative to
definitively substitute Chrome/Silver/Gold electroplating coating onto metals/ceramics/
resin/plaster/glass and plastic materials which is considered to be a strong pollutant and a health hazard.

The most important is the added value brings to producers. The Sputtering PVD processes
enable almost unlimited production of coatings on any type of complex surface. Mostly, for
aesthetic (decorative), functional coating applications.

Vacuum Metal Decoration Magnetron Sputtering System - is designed and produced exclusively for vacuum flask cooper deposition. The depositing layer thickness is up to 2~3 microns which gives extremely good thermal heat preservation.

When add the cathodic arc sources, it can be used for vacuum flask exterior coating to generate various decorative colors: black, gold, blue, rainbow etc.

Vacuum Metal Decoration Copper Magnetron Sputtering Technology Advantages
1. It is totally economically efficient generating the thinnest and most uniform coating films;
2. It is a dry coating process at low temperature in a vacuum chamber;
3. It offers great versatility, can be used for the deposition of conductive or non-conductive materials on any type

of substrates, like: metals, ceramics, plastic materials.
4. Multi layers coating are available.

Vacuum Metal Decoration Magnetron Sputtering System Coating targets:

Chrome , Nickel, Silver, Gold, Titanium targets are applied to generate the high quality thin films on
plastic parts.

MODEL	RTSP-1250
MATERIAL	Stainless Steel (S304)
CHAMBER SIZE	Φ1250*1250mm (H)
PUMP SYSTEM	Rotary Piston Vacuum Pump
	Rotary Vane Vacuum Pump
	Roots Vacuum Pump
	Diffusion Pump
TECHNOLOGY	Magnetron Sputtering Coating+Glow discharging
CONTROL	PLC(Programmable Logic Controller) + Touch Screen
GAS	Gas Mass Flow Meters
SAFETY SYSTEM	Numerous safety interlocks to protect operators and equipment
COOLING	Water
CLEANING	Plasma Source
POWER MAX.	145KW
AVERAGE POWER CONSUMPTION	70KW

PVD Silver Magnetron Sputtering Deposition System

Please contact us for more specifications, Royal Technology is honored to provide you total coating solutions.
